Overview

Basic Info.

Application Range	Data Center
Shell Material	Stainless Steel
Shell Protection Grade	IP55
Brand	Invinstar
Model No.	I-Pd
Voltage	110V~380V
Color	Black
Transport Package	Carton Box or Wooden Pallets
Specification	600W1200D2000H
Trademark	Getwell or customized
Origin	Guangzhou, China
HS Code	850440200
Production Capacity	2000 Per Month

Product Description

High-precision smart power distribution cabinet for micro modular data center

High availability1.Novel and elegant appearance2.The rack color and style can be customized according to the use environment3.Support single-sided single main road, single-sided double main road and double-sided double main road layout4.Flexible incoming and outgoing modes5.The setting of maintenance surface is flexible and convenient for inspection and maintenance.Fully enclosed structure and modular design1.Each functional module is isolated from each other to prevent the operator from directly contacting the bus and prevent foreign matters from contacting the electrical device2.Protection : IP403.All systems comply with the existing national and international standards and specifications, and the components of the products have passed strict quality certificationHigh integration and performance1. Advanced DSP full digital control makes the protection system control faster, more accurate and more stable, and comprehensively improves the reliability.2.The anti-interference ability is enhanced to avoid the inherent hardware parameter drift and other defects of the analog controller and ensure the product consistency.3.High integration and simplified circuit.4.Good performance and highly integrated products ensure more stable and safe operation of the equipment.Comprehensive power quality monitoringIt can monitor complete power quality parameter information and provide key data1.Main circuit measurement parameters include but are not limited to three phase voltage, current, frequency, active power, reactive power, power factor, active electric energy, reactive electric energy, zero ground voltage, neutral line current, total harmonic content (THD), 2nd-63rd harmonic, current voltage unbalance, current K factor (KF), voltage crest factor (CF), telephone waveform factor (thff), peak voltage, voltage and current sequence, ambient temperature and humidity.2.Branch measurement parameters include but are not limited to voltage, current, frequency, active power, reactive power, power factor, active electric energy, reactive electric energy, 2-31 harmonicsIntelligent management1.Effective analysis of all power parameters2.Equipment level energy efficiency management3.Touch screen visualization4.Effective management and risk early warning of key data of each loop5.Provide standardized interfaces to easily connect with third-party systems6.Provide a variety of alarm modes for fault early warning It is necessary to support the access to the energy management platform to form energy consumption classification, sub item and sub regional statistical analysis for the energy consumption and operation information of the data center, so as to realize the visualization of energy management, find out the blind spots of energy consumption, tap the energy-saving potential, and help customers optimize the use of energy. Detailed Photos

High-Precision Smart Power Distribution Cabinet for Micro Modular Data Center

Product Parameters

Name	Quantity ( PCS )
Input Voltage	220/380v
Frequency	50/60Hz±10%2
Output Voltage	220V(1Ph+N+PE);380V(3Ph+N+PE)4
Capacity	10~630A
Distribution Architecture	Support single bus, double bus and multi bus systemsBranch air switch supports fixed switch, hot plug air switch or hot plug adjustable phase air switch
System Function	three phase voltage, current, frequency, active power, reactive power, power factor, active electric energy, reactive electric energy, zero ground voltage, neutral line current, total harmonic content (THD), 2nd-63rd harmonic, current voltage unbalance, current K factor (KF), voltage crest factor (CF), telephone waveform factor (thff), peak voltage, voltage and current sequence, ambient temperature and humidity
System Function	voltage, current, frequency, active power, reactive power, power factor, active electric energy, reactive electric energy, 2-31 harmonics
Accuracy	Incoming line: voltage / current level 0.2, active power / electric energy level 0.5s, reactive power / electric energy level 1
Accuracy	Outgoing line: voltage / current level 0.5, active power / active electric energy / reactive power / reactive electric energy level 1
SPD	Standard C-level surge protection: 20KA, 40KA
Display	Standard 7-inch touch screen, optional 10 inch or above
Communication interface	One way RS485 Modbus-RTU
Communication interface	One way RJ45 10/100m, TCP/IP Modbus Protocol (optional)
Dimension	600/800(W)1000/1100/1200(D)2000/2200(H)mm

Packaging & Shipping
Company Profile
Established in 2008, Guangzhou Getwell Electronics Co., Ltd has been delivering high quality, innovative products and technologies to the IT industry for over 15 years. We focus on data center infrastructure design, construction, manufacturing, operation and maintenance. From 2008 we started to research and develop Micro Modular data center product and build own factory. Getwell pays great attention to R&D and its engineer teams include industrial designer, structure engineers, software engineers, power distribution engineers and HAVC engineers.
Getwell is aimed at continuous improvement product, quality and enlargement of functionality of the products. We keep moving forward learning the world experience in the IT field and needs of our customers, trying to improve and bring our solutions to the level of world IT leaders and even surpassing in some areas. We associates with modern, innovative, convenient, sturdy, secured and high quality product. We follow the tendency of "new generation" of mounting constructions: manufacturing of designs; stable performance and high loading capacity of the structure; low cost on storage and transport thanks to the compact packing and assembling construction. Aim on giving our customers confidence that solutions Getwell guarantees.
FACTORY TOURFAQ

1. Why choose us?

a. we are 15 years factory in producing data center infrastructure products.

b. we have 10+ people in quality management.

c. we have 20+ Process and R&D technicians.

d. we have 10000+ suquare meter factory area.

2. It takes how many days for products preparation?

Usually 25-30 days.

3. What's the trading term for selecting?

FOB, EXW, CIF, CFR, DDP, DDU.

4. I want to buy but I don't have any experience about international trading, what can I do?

Contact the sales for delivery door to door.

5. Which certification we have got?
